Specifications:

Model:HUANANZHI
Item Type: X58 3.0 Motherboard
Mainboard Type:M-ATX
Main Chip: X58 series
Graphics Card Slot: 1*PCI-E 2.0 16X 1*PCI-E2.0 1X 1*PCI
Integrated Video Card: NO
Power Supply: 7 power supply
PCB Layers:6
Ethernet: Gigabit
CPU Type:LGA1366 （X5560/X5570/5650/5675/E5620/w3670.etc）
Memory Slot: 2*DDR3（2 channel）
Memory Capacity Peak: 16Gx2 DDR3
Memory Speed: 1066/1333
Memory type supported: non-ecc/reg ecc/ecc
SATA Interface: SATA2.0x4
USB Interface: USB3.0x4 USB2.0x10(including expansion)
Audio port:ALC662 5.1 channel
Size: 250x185mm
Quantity: 1 Pc

Note:

1:The platform needs powerful power. Please make sure your power supply is sufficient to support it(at least 500w power supply) .
2:Please allow 1-3mm differs due to manual measurement.
3:Due to the different display and different light, the picture may not show the actual color of the item. Thanks for your understanding.
4:The battery in motherboard photos will be removed before shipping, as battery is forbidden at CN post and custom.
5:We show photos of motherboard, pictures are for reference only, subject to our available products.

Note:

For Customs duties problem , pls make sure you can solve the customs clearance problems by yourself, if you can't solve it, we don't advise you to buy goods in our store. We are not responsible for customs duties. Thanks for your kindly understanding！

Note:

Due to computer accessories is toomuch,are likely to have some small brand,bad quality or ES/QS version of the CPU, RAM, M. 2 SSD or other accessories may occur incompatible situation with motherboard.You can confirm with our customer service before purchase. if there is no confirmation before purchase then incompatible happen when you receive the motherboard, we would not accept a refund, when you buy this link of single motherboard we default you have read and know the situation.Mind please don't buy!

We promise to test and deliver the order you submitted within 24 hours

Before Packaging

Our engineers will carry out full-load operation test on the motherboard to ensure the best quality of motherboard shipment
